Pfeiffer Uno 6 (5 m3/h)
HVC-PKD07711
- Single-stage, high-performance rotary vane pump with a pumping speed of 4.8 m3/h at 50 Hz / 5.8 m3/h at 60 Hz
- With single-phase motor with C14 connector plug inside the terminal box
- Integrated gas ballast and safety valve
- OME oil return device is included with the pump
- For all low and medium vacuum applications
- Special feature: Various motor voltages for worldwide employment
- Other motor voltages available on request
- The most compact pumps in this pumping speed class
- Pump Model
- Uno 6
- Voltage & Phases
- 115-230 VAC, 50/60HZ 1-Ø
- Pumping Speed
- 5 m³/h
- Final Pressure
- 3 · 10-2 hPa
- Single-stage, high-performance rotary vane pump with a pumping speed of 4.8 m3/h at 50 Hz / 5.8 m3/h at 60 Hz
- With single-phase motor with C14 connector plug inside the terminal box
- Integrated gas ballast and safety valve
- OME oil return device is included with the pump
- For all low and medium vacuum applications
- Special feature: Various motor voltages for worldwide employment
- Other motor voltages available on request
- The most compact pumps in this pumping speed class
