SPECIFICATIONS
Type DN 10 - 16 ISO-KF DN 20 - 25 ISO-KF DN 32 - 40 ISO-KF
Dimension A 52 61 75
Dimension B 70 81 98
Dimension C 16 16 18
Spring: Steel
Clamping ring half: Aluminum 380.0
Lever: Polyamide
Temperature: Max. 80°C
- Material
- Aluminium - Polyamide
- A (mm)
- 75
- B (mm)
- 98
- C (mm)
- 18
- Flange
- DN 32 - 40 ISO-KF
