Leybold Scrollvac 18 plus
HVC-141018V10
SCROLLVAC plus was built to maintain performance and reliability in the most demanding applications. With the bearings completely separated from the pumping mechanism, you are assured of zero contamination within the vacuum envelope along with exceptional vapor handling.
- Truly dry vacuum pump with pump bearings isolated from the vacuum space eliminating any risk of contamination
- No shaft seal to wear and hence longer service intervals and improved leak tightness
- The ideal dry pump solution for backing turbomolecular and cryo pumps
- Optional C variant may be used for some applications involving the pumping of aggressive media and chemicals
- Pump Model
- Scrollvac 18 plus
- Voltage & Phases
- 115-230 VAC 1-Ø
- Pumping Speed
- 20 m³/h
- Final Pressure
- 3 · 10-2 hPa
