T-Station 85H Dry, DN 63 ISO-K, XDD1, 200-240V
HVC-TS85D2001
T-Station 85H Dry, DN 63 ISO-K, XDD1, 200-240V
T-Station 85 is a low cost, compact turbomolecular pumping station that seamlessly combines the nEXT85H turbomolecular pump with either a dry diaphragm or oil sealed backing pump, and a simple controller, providing pumping speeds of 47 to 84 ls-1.
The T-Station 85 comes with an integrated Turbo and Active Gauge controller which enables single button start/stop of the system. This is combined with the ability to control one of our active gauges, vent valve control and delayed start of the turbomolecular pump to either time or pressure if a gauge is fitted, making the T-Station 85 is ideal for general laboratory needs.
| Pumping speed for N2 | |
| NW40 | 47 ls-1 |
| ISO/CF63 | 84 ls-1 |
| Compression ratio for N2 | >1 x 1011 |
| Backing pump speed | @50 Hz |
| E2M1.5 (TS85H Wet) | 1.6 m3h-1 |
| XDD1 (TS85H Dry) | 1.2 m3h-1 |
| Ultimate vacuum | <5 x 10-8 mbar |
| Inlet flange | NW40, ISO63 or CF63 |
| Exhaust flange | |
| E2M1.5 (TS85H Wet) | 11 mm OD nozzle or 3/8” BSP |
| XDD1 (TS85H Dry) | Fitted silencer or 1/8” BSP |
| Mass | |
| E2M1.5 system (TS85H Wet) | 21 kg max |
| XDD1 system (TS85H Dry) | 17 kg max |
| Noise level | ≤56 dB(A) |
| Leak tightness | <1 x 10-6 mbar ls-1 |
| Operating temperature range | 12 to 40 °C |
