SERIES 216 HV Inline Valve Handquick
HVC-21628-KA04-AAB
- Ergonomically designed knob for secure grip
- Fast open / close actuation with one 130° turn; or a soft continuously variable actuation for controlled venting / pumping of vacuum systems
- Low operating force required, even if the valve is opened against vacuum
- Drive locks into final open / close position
- Visual position indicator, standard
- 316L stainless steel bellows
- Easy maintenance, fast bellows and seal replacement
- High conductance for fast pump down or venting
- High differential pressure resistance
- High purity aluminum or stainless steel body
- Material
- ALU
- Angle / Inline
- Inline
- Flange
- DN25-KF
- Ergonomically designed knob for secure grip
- Fast open / close actuation with one 130° turn; or a soft continuously variable actuation for controlled venting / pumping of vacuum systems
- Low operating force required, even if the valve is opened against vacuum
- Drive locks into final open / close position
- Visual position indicator, standard
- 316L stainless steel bellows
- Easy maintenance, fast bellows and seal replacement
- High conductance for fast pump down or venting
- High differential pressure resistance
- High purity aluminum or stainless steel body
