SERIES 216 HV Inline Valve Handquick
    search
    • SERIES 216 HV Inline Valve Handquick

    SERIES 216 HV Inline Valve Handquick

    HVC-21624-KA04-AAB
    • Ergonomically designed knob for secure grip
    • Fast open / close actuation with one 130° turn; or a soft continuously variable actuation for controlled venting / pumping of vacuum systems
    • Low operating force required, even if the valve is opened against vacuum
    • Drive locks into final open / close position
    • Visual position indicator, standard
    • 316L stainless steel bellows
    • Easy maintenance, fast bellows and seal replacement
    • High conductance for fast pump down or venting
    • High differential pressure resistance
    • High purity aluminum or stainless steel body

    Price on request

    Offerte aanvragen
    Material
    ALU
    Angle / Inline
    Inline
    Flange
    DN16-KF

    Downloaden

    VAT Serie 216

    HV Angle Inline Valve Handquick

    Downloaden (262.18KB)
